RunCam Nano 2 - 700TVL Super WDR FPV Camera 1.8mm (M8) FOV 170°

Introducing the RunCam Nano 2, one of the smallest and lightest FPV cameras on the market. Despite its minuscule size, it packs a powerful punch with a 1/3" CMOS sensor delivering 700TVL resolution. Ideal for micro drones, whoops, and any build where every gram counts, the Nano 2 provides a crisp, clear image with Super WDR technology and a wide 170° field of view. Upgrade your micro FPV experience without compromising on performance or weight.

Key Features

• Ultra Lightweight: Only 3.2g, perfect for micro builds.
• High-Quality Image: 700TVL resolution with a 1/3" CMOS sensor.
• Wide Field of View: 1.8mm lens provides a 170° FOV.
• Excellent Performance: Features Super WDR for great handling of challenging light conditions.
• Versatile: NTSC/PAL switchable via OSD menu.
• Low Power Consumption: Runs on DC 3.3-5.5V, drawing only 110mA@5V.

Specifications

• Model: RunCam Nano 2
• Image Sensor: 1/3" CMOS
• Horizontal Resolution: 700TVL
• Lens: 1.8mm (M8) FOV 170°
• Screen Format: 4:3
• Signal System: NTSC / PAL Switchable
• S/N Ratio: >50dB
• Electronic Shutter Speed: Auto
• Auto Gain Control (AGC): Auto
• Min. Illumination: 0.01Lux@1.2F
• WDR: Super WDR
• Day/Night: Color
• Menu Control: Cable Control
• Power: DC 3.3-5.5V
• Current: 110mA @ 5V
• Housing Material: ABS
• Net Weight: 3.2g
• Dimensions: 14mm x 14mm x 16mm

Package Includes

• 1x RunCam Nano 2 Camera
• 1x 3-pin 1.25mm JST Silicone Cable
• 1x Set of Screws
• 1x User Manual
